NEMA4X/IP69
INDUSTRIAL DISPLAYS
12.1” Industrial Display
ID1210M
Specifications
Size: 12.1″ LCD
Maximum Resolution: 1024 x 768
Standard Format
Contrast Ratio: 1000:1
Aspect Ratio: 4:3
Brightness: 500 nits (No Touch), 425 nits (P-CAP)
View Angle: H: 178°, V: 178°
Video Port: 1 x VGA, 1 x DP, 1 x HDMI
Warranty: 5 year
Description
This 12.1″ monitor delivers a newly developed, commercial-grade open frame solution. The standard configuration features a painted CRS chassis and a no-touch display. Optional upgrades include stainless steel construction and projected capacitive touch. A gasketed standard bezel and integrated cable management promote a clean and streamlined installation. The compact design is complemented by a low-profile cable management bracket. This monitor is configurable to meet a broad range of application needs.
Standard Configuration
$785
Stainless Steel
Touch Screen
+$100
+$40
15” Industrial Display
ID1500M
Specifications
Size: 15″ LCD
Maximum Resolution: 1024 x 768
Standard Format
Contrast Ratio: 1000:1
Aspect Ratio: 4:3
Brightness: 500 nits (No Touch), 425 nits (P-CAP)
View Angle: H: 178°, V: 178°
Video Port: 1 x VGA, 1 x DP, 1 x HDMI
Warranty: 5 year
Description
This 15″ monitor features a newly engineered, commercial-grade open frame design. The standard configuration includes a painted CRS chassis and a no-touch display. Stainless steel construction and projected capacitive touch are available options. A standard gasketed bezel and integrated cable management maintain a clean and professional installation. A slim cable management bracket complements the refined, versatile design. This monitor supports custom configurations to meet a wide range of application requirements.
Standard Configuration
$815
Stainless Steel
Touch Screen
+$100
+$20
15.6” Industrial Display
ID1560M
Specifications
Size: 15.6″ LCD
Maximum Resolution: 1024 x 768
Widescreen Format
Contrast Ratio: 1000:1
Aspect Ratio: 4:3
Brightness: 500 nits (No Touch), 425 nits (P-CAP)
View Angle: H: 178°, V: 178°
Video Port: 1 x VGA, 1 x DP, 1 x HDMI
Warranty: 5 year
Description
The 15.6″ monitor offers a modernized open frame design built for industrial environments. It comes standard with a painted CRS chassis and a no-touch display. Optional features include stainless steel construction and projected capacitive touch. A gasketed bezel and internal cable management contribute to a clean, organized integration. The enclosure includes a slim, purpose-built cable bracket and supports a range of custom configurations for varied system requirements.
Standard Configuration
$845
Stainless Steel
Touch Screen
+$100
+$30
17” Industrial Display
ID1700M
Specifications
Size: 17″ LCD
Maximum Resolution: 1280 x 1024
Standard Format
Contrast Ratio: 800:1
Aspect Ratio: 5:4
Brightness: 250 nits (No Touch), 215 nits (P-CAP)
View Angle: H: 160˚, V: 160˚
Video Port: 1 x VGA, 1 x DVI
Warranty: 5 year
Description
This industrial-grade 17″ open frame monitor is the perfect solution for a wide variety of embedded applications. Uniquely designed with the glass settling proud of the bezel allowing for a seamless fit into a broad range of kiosks and fixtures, exceeding your integration expectations – The IP65 rating, 10-point touch, 1280 x 1024 resolution and innovative bezel design encourages a memorable end-user experience that outperforms the competition with a dependable, reliable, performance driven product.
Standard Configuration
$825
Stainless Steel
Touch Screen
+$100
+$20
19” Industrial Display
ID1900M
Specifications
Size: 19″ LCD
Maximum Resolution: 1280 x 1024
Standard Format
Contrast Ratio: 1000:1
Aspect Ratio: 5:4
Brightness: 250 nits (No Touch), 215 nits (P-CAP)
View Angle: H: 178°, V: 178°
Video Port: 1 x VGA, 1 x DP, 1 x HDMI
Warranty: 5 year
Description
This industrial-grade 19″ open frame monitor is the perfect solution for a wide variety of embedded applications. Uniquely designed with the glass settling proud of the bezel allowing for a seamless fit into a broad range of kiosks and fixtures, exceeding your integration expectations – The IP65 rating, 10-point touch, 1280×1024 resolution and innovative bezel design encourages a memorable end-user experience that outperforms the competition with a dependable, reliable, performance driven product.
Standard Configuration
$865
Stainless Steel
Touch Screen
+$100
+$20
20” Industrial Display
ID2000M
Specifications
Size: 19.5″ TFT LCD
Maximum Resolution: 1920 x 1080
Widescreen Format
Contrast Ratio: 1000:1
Aspect Ratio: 4:3
Brightness: 250 nits (No Touch), 212 nits (P-CAP)
View Angle: H: 178°, V: 178°
Video Port: 1 x VGA, 1 x DP, 1 x HDMI
Warranty: 5 year
Description
This monitor is a 19.5″, newly designed, commercial-grade open frame solution. The refined aesthetics, standard gasketed bezel, and cable management feature ensures that the customer specific application remains clean, aesthetically remarkable with the ability to endure harshest of environments. A stylish thin cable management bracket and versatile design, this monitor is an exceptional choice for applications for all business sectors and well suited for point-of-sales, point-of-information, point-of-service and interactive signage. This monitor retains all capabilities to mold a unique solution for any customer application.
Standard Configuration
$915
Stainless Steel
Touch Screen
+$100
+$10
22” Industrial Display
ID2200M
Specifications
Size: 21.5″ LCD
Maximum Resolution: 1920 x 1080
Widescreen Format
Contrast Ratio: 1000:1
Aspect Ratio: 16:9
Brightness: 350 nits (No Touch), 315 nits (P-CAP)
View Angle: H: 178°, V: 178°
Video Port: 1 x VGA, 1 x DP, 1 x HDMI
Warranty: 5 year
Description
This industrial-grade 22″ open frame monitor is the perfect solution for a wide variety of embedded applications. Uniquely designed with the glass settling proud of the bezel allowing for a seamless fit into a broad range of kiosks and fixtures, exceeding your integration expectations – The IP65 rating, 10-point touch, 1920×1080 resolution and innovative bezel design encourages a memorable end-user experience that outperforms the competition with a dependable, reliable, performance driven product.
Standard Configuration
$955
Stainless Steel
+$20
Touch Screen
+$100
24” Industrial Display
ID2400M
Specifications
Size: 23.8″ LCD
Maximum Resolution: 1920 x 1080
Widescreen Format
Contrast Ratio: 3000:1
Aspect Ratio: 16:9
Brightness: 250 nits (No Touch), 215 nits (P-CAP)
View Angle: H: 178°, V: 178°
Video Port: 1 x VGA, DP x 1, HDMI x 1
Warranty: 5 year
Description
This monitor is a 24″, newly designed, commercial-grade open frame solution. The refined aesthetics, standard gasketed bezel, and cable management feature ensures that the customer specific application remains clean, aesthetically remarkable with the ability to endure harshest of environments. A stylish thin cable management bracket and versatile design, this monitor is an exceptional choice for applications for all business sectors and well suited for point-of-sales, point-of-information, point-of-service and interactive signage. This monitor retains all capabilities to mold a unique solution for any customer application.
Standard Configuration
$1055
Stainless Steel
Touch Screen
+$100
+$20
32” Industrial Display
ID3200M
Specifications
Size: 31.5″ LCD
Maximum Resolution: 1920 x 1080
Widescreen Format
Contrast Ratio: 3000:1
Aspect Ratio: 16:9
Brightness: 500 nits (No Touch), 450 nits (P-CAP)
View Angle: H: 178°, V: 178°
Video Port: 1 x VGA, 1 x DP, 1 x HDMI 1.3
Warranty: 5 year
Description
This 32″ Full HD (1920 x 1080) monitor features an ultra-slim open frame design built for high-performance applications. The standard configuration includes a painted CRS chassis and a no-touch display. Projected capacitive (PCAP) 30-point touch is available as an option. With a 20 mm slim bezel, high contrast display, and versatile I/O support, this monitor combines aesthetics and functionality in a large-format solution. Suitable for a range of integration scenarios, it is designed to adapt to both interactive and non-interactive environments.
Standard Configuration
$1545
Stainless Steel
Touch Screen
+$100
+$30
