NEMA 4, Powder Coated, Flat Top, Handle and Gas Springs on Door Cable Entry Plate, Wall Mount Tilt Bracket

Features a flat-top NEMA 4 enclosure with a handle and gas springs on the door, as well as a cable entry plate and wall mount tilt bracket.

Specific Product Features

• NEMA 4

• Aluminum

• Powder Coated

• Flat Top

• Handles and Gas Springs on Door

• Cable Entry Plate

• Wall Mount Tilt Bracket

Want to learn more about this product or one of our other solutions? Contact Us!

NEMA 4X, Flat Top, Handles and Gas Springs on Door, Insulation, Solid State Cooler

NEMA 4X flat-top unit with handles and gas springs on the door, enhanced with insulation and a solid-state cooler.

Specific Product Features

• NEMA 4X

• Flat Top

• Handles and Gas Springs on Door

• Insulation

• Solid State Cooler

Want to learn more about this product or one of our other solutions? Contact Us!

Stainless Steel Touchscreen Display HMI for Washdown and Hygienic/Aseptic Environments

The 55” Interactive Touch Display HMI is a sealed stainless steel designed for hygienic/aseptic manufacturing floors in the pharmaceutical world. Built from polished stainless steel (304 or 316), the enclosure supports frequent cleaning and long-term durability in food processing, pharmaceutical manufacturing, clean room, and other hygienic/aseptic production environments.

The integrated 55” multi-touch projected capacitive display supports glove-friendly operation and provides 4K resolution (3840 × 2160) for clear visualization of process data, dashboards, and control systems.

The enclosure provides secure internal mounting for a PC or thin client, eliminating the need for proprietary hardware. Sealed cable glands and through-panel connections provide protected access for ethernet, power, and USB devices while maintaining NEMA 4X / IP69 environmental protection.

Image shown with optional Mobile Mounting system attached.

Featured Specifications

• SUS 304 stainless steel for ease of cleaning in hygienic/aseptic clean room environments

• 55” multi-touch glove friendly projected capacitive screen

• Easy Installation for your PC or thin client, no need for proprietary equipment

• Sealed connections for ethernet, power and 2x USB

• Wireless Options

• Mobile (shown) / Wall / Ceiling mounting options

Technical Specifications

Display

• Size: 55” TFT LCD

• Projected capacitive touch

• Maximum Resolution: 3840 × 2160

• Contrast Ratio: 1200:1

• Aspect Ratio: 16:9

• Brightness: 450 nits

• View Angle: H: 178˚, V: 178˚

• Video Port: 2x HDMI / 1x DisplayPort / 1x VGA

Enclosure

• NEMA 4X / IP69

• 304 and 316 polished stainless steel construction options

• Dimensions: 53” W × 7” D × 35” H

• Knife edge opening design with full gasket seal

• Rear door for easy maintenance

• Keyed access latches

• External push button on/off switch

• 15’ power cord

• 2x cable glands for power and ethernet

• 2x quick disconnect USB through panel

• Power distribution panel with 4 outlet industrial grade surge suppressor

Aluminum, Flat Top, Compression Box, External Power Switch, Hanging Eyes

NEMA 4 enclosure with a flat-top design, front door, external power switch, compression box, and hanging eyes, includes gas springs on the door.

Specific Product Features

• NEMA 4

• Aluminum

• Powder Coated

• Flat Top

• Front Door

• External Power Switch

• Compression Box

• Eye Bolts

• Gas Springs on Door

Want to learn more about this product or one of our other solutions? Contact Us!

Stainless Steel Touchscreen Display HMI for Washdown and Hygienic/Aseptic Environments

The 32” Interactive Touch Display HMI is a sealed stainless steel (304 or 316 options) workstation designed for industrial environments requiring rugged construction and washdown capability.

Constructed from polished stainless steel, the enclosure is built for durability and easy cleaning in sanitary production environments such as food processing, pharmaceutical manufacturing, and clean room facilities.

The integrated 32” projected capacitive multi-touch display supports glove operation and provides Full HD resolution (1920 × 1080) for industrial applications including recipe monitoring, process monitoring, and data visualization.

The enclosure includes sealed cable glands, through-panel USB connectors, and internal power distribution to securely integrate your PC or thin client while maintaining NEMA 4X / IP69 environmental protection.

Image shown with optional Mobile Mounting system attached.

Featured Specifications

• SUS 304 or 316 stainless steel for ease of cleaning in hygienic/aseptic clean room environments

• 32” multi-touch glove friendly projected capacitive screen

• Easy installation for your PC or thin client, no need for proprietary equipment

• Sealed connections for ethernet, power and 2x USB

• Wireless options

• Mobile (shown) / Wall / Ceiling mounting options

Technical Specifications

Display

• Size: 31.5” TFT LCD

• Projected capacitive touch

• Maximum Resolution: 1920 × 1080

• Contrast Ratio: 3000:1

• Aspect Ratio: 16:9

• Brightness: 450 nits

• View Angle: H: 178˚, V: 178˚

• Viewable Diagonally: 31.5”

• Video Port: 1x HDMI / 1x DisplayPort / 1x VGA

Enclosure

• NEMA 4X / IP69

• 304 or 316 polished stainless steel construction

• Dimensions: 36” W × 6.7” D × 24.5” H

• Removable front door for easy maintenance access

• Knife edge door opening with full gasket seal

• Sloped top

• Keyed access latches

• External push button on/off switch

• 15’ power cord

• 2x cable glands for power and ethernet

• 2x quick disconnect USB through panel

• Power distribution panel and terminal blocks

• Blind inserts to accept mounting options

Aluminum, Flat Top

Flat-top NEMA 4 unit, powder-coated, featuring handles and gas springs on the door.

Specific Product Features

• NEMA 4

• Aluminum

• Powder Coated

• Flat Top

• Handles and Gas Springs on Door

Want to learn more about this product or one of our other solutions? Contact Us!
